CANADIAN HYDROGRAPHIC SERVICE - ANNOUNCEMENT REGARDING CANADIAN HYDROGRAPHIC SERVICE CHART PATCHES

Colour Web Patches are free to the mariner, and given the quality of many printers, should reproduce well. They will be available in real time all around the world.

CHS welcomes your feedback on this service at chsinfo@dfo-mpo.gc.ca.

CANADIAN HYDROGRAPHIC SERVICE - CUMULATIVE CHART CORRECTIONS

The cumulative Notices to Mariners corrections for charts can now be accessed at

www.notmar.gc.ca/search/notmar-eng.php .

CANADIAN HYDROGRAPHIC SERVICE - Current chart edition dates

CHART EDITIONS
The three terms described below are used to indicate the publication status of Canadian charts.

NEW CHART - "NEWCHT"
The first publication of a Canadian chart embracing an area not previously charted to the scale shown, or embracing an area different from any existing Canadian chart.

NEW EDITION - "NEWEDT"
A new issue of an existing chart containing amendments essential to navigation in addition to those issued in Notices to Mariners and making existing editions obsolete.

REPRINTS
A new issue of the current edition of a chart incorporating no amendments of navigational significance other than those previously promulgated in Notices to Mariners. It may also contain amendments from other sources provided they are not essential to navigation. Previous printings of the current edition remain in force.

The current chart edition dates can be accessed at www.chs-shc.gc.ca/charts-cartes/paper-papier/index-eng.asp

CANADIAN HYDROGRAPHIC SERVICE - PRINT ON DEMAND CHARTS - CARE AND USE

Background
By providing nautical charts to the public, the goal of the Canadian Hydrographic Service (CHS) is to provide services for safe navigation in a fiscally responsible manner. As a result, CHS continues to expand its portfolio of nautical paper charts that are printed using Print On Demand (POD) technology. These charts are easily recognized by their whiter paper and the coloured logo of the Canadian Hydrographic Service. This new technology enables CHS to print charts in a more efficient manner while enhancing chart content through being able to quickly add new and important information. POD technology provides customers with up-to-date charts without the historical hand-drawn corrections or glued-on patches. Additionally, this technology eliminates out-of-stock situations which arise with the traditional printing and warehousing methods. In the event of a national emergency, CHS can respond to the appropriate authorities with best available information very quickly.

Care of Your POD Chart
CHS encourages its customers to handle the POD charts more carefully than the traditional lithographic charts. When plotting information on POD charts, use HB pencils and apply limited pressure. Testing has suggested that an Indian gum eraser is more effective than alternatives when used on the product. This eraser is also suitable for charts printed using lithographic processes.

CANADIAN HYDROGRAPHIC SERVICE - TRANSPORT CANADA NAVIGATION SAFETY - ECDIS

Mariners are advised that ECDIS may not display some isolated shoal depths when operating in "base or standard display" mode. Route planning and monitoring alarms for these shoal depths may not always be activated. To ensure safe navigation and to confirm that a planned route is clear of such dangers, mariners should visually inspect the planned route and any deviations from it using ECDIS configured to display "all data". The automated voyage planning check function should not be solely relied upon.

UPDATE TO CONSOLIDATION OF MARINE COMMUNICATIONS AND TRAFFIC SERVICES (MCTS) CENTRES

The Canadian Coast Guard is modernizing and consolidating its Marine Communications and Traffic Services Centres. Clients will continue to receive the high-quality service they have come to expect.

Once complete, there will be a total of 12 MCTS Centres strategically located across the country. Additional information pertaining to this project will be advertised to clients by all available means


Atlantic Region

Saint John (Fundy) MCTS Centre will consolidate to Halifax MCTS Centre commencing March 2015
St. John’s MCTS Centre will consolidate to Placentia MCTS Centre commencing March 2015
St. Anthony MCTS Centre will consolidate to Labrador (Goose Bay) MCTS Centre commencing August 2015


Central & Arctic Region

Thunder Bay MCTS Centre will consolidate to Sarnia MCTS Centre commencing May 2015.
Rivière-au-Renard MCTS centre will consolidate to Les Escoumins MCTS centre commencing June 2015.


The new technology will increase efficiency permitting employees to have a greater ability to focus on the safety services they provide to mariners. Mariners are encouraged to visit the Radio Aids to Marine Navigation (RAMN) http://www.ccg-gcc.gc.ca/Marine-Communications/Home and Notices to Mariners (NOTMAR) http://www.notmar.gc.ca/ PART 3 on a monthly basis for updated information and potential changes to contact information and marine broadcast schedules.

SAGUENAY-ST. LAWRENCE MARINE PARK AND SURROUNDING WATERS - WHALE PROTECTION.

The waters in and around the Saguenay-St. Lawrence Marine Park are well known for their resident threatened beluga population and the wide diversity of whales that migrate there to feed, particularly between April and November.

REGULATORY PROTECTION MEASURES

All whale species that are found in the St. Lawrence are protected under the Marine Mammal Regulations, pursuant to the Fisheries Act. Within the boundaries of the Marine Park, specific measures are set out in the Marine Activities in the Saguenay–St. Lawrence Marine Park Regulations, pursuant to the Act Establishing the Saguenay-St. Lawrence Marine Park. Any collision with a marine mammal within the Marine Park must immediately be reported to a park warden at 1-866-508-9888. For collisions that occur outside the Marine Park or for any situation involving a marine mammal that is dead or in trouble, contact the emergency network at 1-877-722-5346 or on channel 16.

For more information on the Saguenay-St. Lawrence Marine Park, see section 5C of the Annual Edition of the Notices to Mariners – April 2015 to March 2016.

VOLUNTARY PROTECTION MEASURES

Provisional measures in effect from May 1st to October 31st, 2015. See map below.

These measures apply to merchant vessels and cruise ships between Pointe à Boisvert and Cap de la Tête au Chien to prevent collisions with whales. These measures should only be taken when they will not jeopardize navigational safety.

Caution area (yellow area) : To reduce the risk of collisions with whales that can be present anywhere in this area, heightened vigilance of navigators is critical. Posting a lookout is recommended in order to increase the chances of seeing the whales and thus taking necessary measures to avoid them. If bypassing the whales is not possible, slow down and wait for the animals to move away to a distance greater than 400 meters (0.215 nautical miles) before resuming original speed. It is more difficult to see the animals at night therefore increased caution is recommended.

Slow down to 10 knots or less area (red area) : To reduce the risk of collisions with whales in this feeding area, it is recommended that vessels slow down to a maximum speed through the water of 10 knots and post a lookout. It is further recommended to remain in the Laurentian Channel to the north of Île Red to minimize the impact of noise in a sensitive area south of this island, which is highly frequented by herds of beluga whales composed of females and young.

Area to be avoided (hatched red area) : To reduce noise and the risk of collisions with whales, vessels should avoid transiting through this area which is highly frequented by blue whales, an endangered species. If the area cannot be avoided, slow down to a speed through the water of 10 knots or less.

TRANSPORT CANADA - RESTRICTED SPEED AREA - ST. CLAIR AND DETROIT RIVER.

Since November 14, 2012 the restricted speed area currently in place as per the St. Clair and Detroit River Navigation Safety Regulation between the Detroit River light and Peche Island light is reduced in size by relocating the southern point of the restricted speed area from its current location at the Detroit River light to a new location at Bar Point light D33. (This notice refers to the previous one published in November 2012 with number *1103)

CANADIAN COAST GUARD PUBLICATION - RADIO AIDS TO MARINE NAVIGATION (ATLANTIC, ST. LAWRENCE, GREAT LAKES, LAKE WINNIPEG AND EASTERN ARCTIC) PUBLICATION - 2013 - The Commercial Public Correspondence Service.

Part I - Page 1 of 10

ADVANCE NOTICES

The Commercial Public Correspondence Service

Effective January 1, 2014, the following changes to the Canadian Coast Guard commercial public correspondence service, provided through select Marine Communications and Traffic Services centres, will be in effect: All long distance ship-shore calls will be administered through the regular telephone service provider as acollect call. Individuals intending to placeshore-ship calls will be required to direct-dial the appropriate MCTS centre. MCTS centres providing a commercial public correspondence service are identified in RAMN, Part 2.

ERRATUM: REFERENCE NOTICE 808P/2015

AMEND
Chart: 2421
TO READ
Chart 4210

*901 CANADIAN HYDROGRAPHIC SERVICE - NAUTICAL CHARTS.

CHARTS	MAIN TITLE	SCALE	PUBLISHED	CAT#	PRICE
New Editions
4114	Campobello Island	1:20000	24-APR-2015	1	20.00
4430	Plans - Île D'Anticosti	1:72000	22-MAY-2015	1	20.00
4841	Cape St Mary's to/à Argentia	1:60000	27-AUG-2015	1	20.00
7920	Tanquary, Slidre and Glacier Fiords	1:100000	15-MAY-2015	4	20.00

*902 CANADIAN HYDROGRAPHIC SERVICE - ELECTRONIC NAVIGATIONAL CHART

NEW PRODUCTS
S-57 ENC NUMBER	CHART TITLE
CA376293	Head of / Fond de St Mary's Bay
CA376625	Cape Ray to/à Garia Bay
CA476108	Renews Harbour
CA576626	Burnt Island

*903 TRANSPORT CANADA – SHIP SAFETY BULLETIN.

This is to notify you that a new Ship Safety Bulletin has recently been posted to the Transport Canada website at: www.tc.gc.ca/ssb-bsn/

To go online to view or download this bulletin, please click on the link below:

Subject: Marine Transportation of Packaged Dangerous Goods: Transport Canada’s New One-Window Approach to issuing MTRB Decisions and Related TDG Equivalency Certificates.

SSB#08/2015 – Loading and Unloading Explosives
RDIMS#10795358

Sign yourself up for e-Bulletin to receive an e-mail notice each time a new Ship Safety Bulletin is published on our Web site.
Contact us at: marinesafety-securitemaritime@tc.gc.ca or 1-855-859-3123 (Toll Free).

*904(P) WEDGPORT AND THE VICINITY- ADVERTISEMENT OF PROPOSED CHANGE

Reference Chart: 4244

The Canadian Coast Guard proposes the following permanent changes to

Hell’s Gate RR-NS - LLNO 7282.2: Change Hell's Gate yellow cautionary mast with radar reflector to yellow north cardinal mast with radar reflector, top marks and 2 horizontal bands of white retro reflective tape.

Comments on this action are solicited from mariners and other interested parties.
Comments should be directed to the

Superintendent,
Aids to Navigation, Canadian Coast Guard by mail to
PO Box 5667,
St. John’s, Newfoundland
A1C 5X1
Phone at 709-772-5195,
E-mail: denise.veber@dfo-mp.gc.ca

Within three months from the date of this Notice. Any objections raised must state the facts on which they are based and should include supporting information on safety, commerce and public benefit.

(F2015028)

*905 CANADIAN HYDROGRAPHIC SERVICE - SAILING DIRECTIONS BOOKLET- CEN 306- GEORGIAN BAY, SECOND EDITION, 2015 IS NOW AVAILABLE AS A PRINT ON DEMAND (POD).

Georgian Bay, Second Edition, 2015  cancels and replaces Sailing Directions booklet CEN 306 — Georgian Bay, First Edition, 1998. This new booklet is now available as a Print-on-Demand (POD) product. POD booklets are corrected through Section 4 of Notices to Mariners up to the date of printing. The price of CEN 306, Second Edition, is $19.95. Advance orders may be made through any authorized CHS Dealer.

---

2110 - Long Point Bay - New Edition - 29-MAY-1998 - NAD 1983
11-SEP-2015		LNM/D. 21-AUG-2015
Add	wreck WK with known depth of 8.3 metres (See Chart No 1, K26) This notice affects Electronic Navigational Chart: CA373093, CA473305, CA573306	42°45′55.0″N 080°03′02.8″W
DFO(6604129-01)
2110 - Nanticoke Harbour - New Edition - 29-MAY-1998 - NAD 1983
11-SEP-2015		LNM/D. 21-AUG-2015
Add	wreck WK with known depth of 8.3 metres (See Chart No 1, K26) This notice affects Electronic Navigational Chart: CA373093, CA473305, CA573306	42°45′55.0″N 080°03′02.8″W
DFO(6604129-01)
2120 - Niagara River to/à Long Point - New Edition - 15-APR-2005 - NAD 1983
11-SEP-2015		LNM/D. 21-AUG-2015
Add	wreck WK with known depth of 8.3 metres (See Chart No 1, K26) This notice affects Electronic Navigational Chart: CA373093, CA473305, CA573306	42°45′55.0″N 080°03′02.8″W
DFO(6604129-01)
2123 - Pelee Passage to/à la Detroit River - New Edition - 27-JAN-2006 - NAD 1983
04-SEP-2015		LNM/D. 25-JUL-2014
Delete	Bell from green port hand lighted pillar buoy, marked 1W, Fl G 6s (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA373089	41°57′01.0″N 083°09′32.3″W
(USCG:LNM 30/15) DFO(6604126-01)
4116 - Approaches to/Approches à Saint John - New Edition - 31-AUG-2007 - NAD 1983
25-SEP-2015		LNM/D. 24-JUL-2015
Replace	obstruction, depth unknown and legend ″Obstn PA Rep (1997)″ with depth of 27 metres, 1 decimetre (See Chart No 1, K40 & I10) This notice affects Electronic Navigational Chart: CA376011	45°10′30.0″N 066°05′36.0″W
DFO(6307288-01)
4449 - Grand Etang Harbour - New Edition - 03-JUL-1998 - NAD 1983
18-SEP-2015		LNM/D. 05-DEC-2014
Affix	patch Download patch - http://www.chs-shc.gc.ca/patches/4449PA_20150806.pdf	46°33′00.0″N 061°02′40.0″W
DFO(6307252-01)
4463 - Chéticamp to/à Cape Mabou - New Edition - 27-JUN-2003 - NAD 1983
18-SEP-2015		LNM/D. 10-FEB-2012
Delete	depth of 2 fathoms, 2 feet (See Chart No 1, I10)	46°33′11.4″N 061°02′45.3″W
DFO(6307252-03)
Add	depth of 0 fathoms, 3 feet (See Chart No 1, I10)	46°33′08.7″N 061°02′44.1″W
DFO(6307252-04)
4909 - Richibucto Harbour - New Chart - 17-JUN-1988 - NAD 1983
18-SEP-2015		LNM/D. 24-APR-2015
Replace	green port hand can buoy, marked Q39 with green port hand lighted spar buoy FlG, marked Q39 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	46°41′19.0″N 064°50′56.0″W
(G2015100 & G2015101) LL(1150.1) DFO(6307228-01)
Delete	red starboard hand conical buoy, marked Q42 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	46°41′09.1″N 064°51′21.0″W
(G2015102) DFO(6307228-02)
Add	red starboard hand lighted pillar buoy QR, marked Q42 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	46°41′05.9″N 064°51′18.8″W
(G2015103) LL(1150.11) DFO(6307228-03)
Add	red starboard hand conical buoy, marked Q14 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	46°42′36.5″N 064°45′55.0″W
(G2015104) DFO(6307228-04)
Add	green port hand can buoy, marked Q23 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	46°42′47.3″N 064°47′15.7″W
(G2015105) DFO(6307228-05)
Reposition	green port hand lighted pillar buoy QG, marked Q11 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	from 46°42′34.2″N 064°45′46.9″W to 46°42′28.4″N 064°45′35.2″W
(G2015106) LL(1134) DFO(6307228-06)
Reposition	red starboard hand lighted pillar buoy QR, marked Q22 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	from 46°42′44.4″N 064°46′39.0″W to 46°42′47.2″N 064°46′55.7″W
(G2015109) LL(1136) DFO(6307228-07)
Reposition	green port hand lighted pillar buoy QG, marked Q25 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	from 46°42′51.0″N 064°47′46.2″W to 46°42′50.6″N 064°48′00.2″W
(G2015110) LL(1144) DFO(6307228-08)
Reposition	red starboard hand lighted pillar buoy QR, marked Q32 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	from 46°42′11.3″N 064°49′14.7″W to 46°42′14.2″N 064°49′02.9″W
(G2015111) LL(1147) DFO(6307237-01)
Reposition	green port hand can buoy, marked Q35 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	from 46°41′44.5″N 064°50′09.7″W to 46°41′48.8″N 064°50′06.0″W
(G2015112) DFO(6307237-02)
Replace	red starboard hand conical buoy, marked Q24 with red starboard hand lighted conical buoy FlR, marked Q24 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	46°42′53.5″N 064°47′34.0″W
(G2015113 & G2015114) LL(1136.1) DFO(6307237-03)
Reposition	red starboard hand lighted pillar buoy FlR, marked Q18 (See Chart No 1, Qf) This notice affects Electronic Navigational Chart: CA476131	from 46°42′37.8″N 064°46′01.8″W to 46°42′40.1″N 064°46′12.5″W
(G2015107) LL(1135) DFO(6307237-04)
Delete	green port hand can buoy, marked Q19 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	46°42′39.6″N 064°47′02.4″W
(G2015108) DFO(6307237-05)
Add	green port hand can buoy, marked Q19 (See Chart No 1, Qg) This notice affects Electronic Navigational Chart: CA476131	46°42′40.9″N 064°46′37.7″W
(G2015108) DFO(6307237-06)

---

*906 RADIO AIDS TO MARINE NAVIGATION 2015 (ATLANTIC, ST. LAWRENCE, GREAT LAKES, LAKE WINNIPEG AND ARCTIC)

Part 1 - Page 9

REMOVE the following line :

Table 1-4 - Telephone / Facsimile / Telex Directory

St Anthony,NL (VCM)

709-454-3852

709-454-3716

003160021

Part 1 - Page 11

AMEND
1.7 Regional Office Addresses (covering the East Coast, Arctic and Central Canada)

Regional Superintendent
Marine Communications and Traffic Services

Fisheries and Oceans Canada
Canadian Coast Guard
Atlantic Region
P.O. Box 5667
St. John’s NL A1C 5X1
Telephone: 709-772-5119
Facsimile: 709-772-6050

TO READ

Fisheries and Oceans Canada
Canadian Coast Guard
Atlantic Region
P.O. Box 1000
St. John’s NL A1C 5X1
Telephone: 902-426-3797
Facsimile: 902-426-4828

Part 2 - Page 8

AMEND

Table 2-3 - MCTS Iqaluit / VFF – Ship/Shore Communications

Killinek 60°25'27"N 064°50'30"W

403

2182J3E 2514J3E 2582J3E 4363J3E

2182 2118 2206 4071

This site is operational approximately early July to late October.

TO READ

Killinek 60°25'27"N 064°50'30"W

403

2182J3E 2514J3E 2582J3E 4363J3E

2182 2118 2206 4071

This site is operational approximately early July to mid-December.

Part 2 - Page 17

ADD the following line:

For Vessel Traffic Services call Belle Isle Traffic – refer to Part 3.

AMEND
Email : ECAGOY@INNAV.GC.CA

TO READ

Email : Safety.Labrador@innav.gc.ca

AMEND

Table 2-5 - MCTS Labrador / VOK – Ship/Shore Communications

Sites located at	Channel	Frequencies		Remarks
		Transmit	Receive
Cartwright 53°42'30"N 057°01'17"W	407	2182J3E 2514J3E 2538J3E 2582J3E 4375.0J3E	2182 2118 2142 2206 4083.0	407, 2118, 2142, 2206 and 4083.0: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Hopedale 55°27'24"N 060°12'30"W	407 605 Ch16 Ch26 Ch70	2182J3E 2514J3E 2538J3E 2582J3E 4375.0J3E 6513J3E	2182 2118 2142 2206 4083.0 6212	407, 605, Ch26, 2118, 2142, 2206, 4083.0 and 6212: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Cartwright 53°43'38"N 056°58'06"W	Ch16 Ch24 Ch70			Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Goose Bay 53°18'12"N 060°31'27"W	Ch16 Ch26 Ch70			Ch26: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Nain 56°32'49"N 061°42'49"W	C16 C24 C70			Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.

TO READ

Sites located at	Channel	Frequencies		Remarks
		Transmit	Receive
Cartwright 53°42'30"N 057°01'17"W	407	2182J3E 2514J3E 2538J3E 2582J3E 4375.0J3E	2182 2118 2142 2206 4083.0	407, 2118, 2142, 2206 and 4083.0: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Hopedale 55°27'24"N 060°12'30"W	407 605 Ch16 Ch26 Ch70	2182J3E 2514J3E 2538J3E 2582J3E 4375.0J3E 6513J3E	2182 2118 2142 2206 4083.0 6212	407, 605, Ch26, 2118, 2142, 2206, 4083.0 and 6212: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Cartwright 53°43'38"N 056°58'06"W	Ch16 Ch24 Ch70			Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Goose Bay 53°18'12"N 060°31'27"W	Ch16 Ch26 Ch70			Ch26: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Nain 56°32'49"N 061°42'49"W	Ch16 Ch24 Ch70			Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.
St. Anthony (Newfoundland) 51°30'00"N 055°49'26"W		2182J3E 2514J3E 2582J3E	2182 2118 2206	2118 and 2206: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Comfort Cove (Newfoundland) 49°16'26"N 054°52'32"W	Ch16 Ch26 Ch70			Ch26: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Twillingate (Newfoundland) 49°41'10"N 054°48'00"W	Ch16 Ch24 Ch70			VHF Direction Finding service is available. Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.
L’Anse aux Meadows (Newfoundland) 51°34'20"N 055°29'27"W	Ch14 Ch16 Ch24 Ch70			Ch24: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Conche (Newfoundland) 50°53'41"N 055°53'03"W	Ch16 Ch26 Ch70			C26: Facilities are available for connecting ships directly to the commercial telephone system on shore.
Fox Harbour 52°22'10"N 055°39'42"W	Ch16 Ch26 Ch70			Ch26: Facilities are available for connecting ships directly to the commercial telephone system on shore.

Part 2 - Page 18

AMEND

Table 2-6 - MCTS Labrador / VOK – Broadcasts

Time UTC	Site	Frequency or Channel	Contents
01:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas: 222, 223, 224, 225, 226, 227, 228, 229 and 230. • Ice Edge & Conditions for Labrador Coast.
	Hopedale	2598J3E
03:50	Labrador	518F1B	NAVTEX : (X) • Weather.
07:50	Labrador	518F1B	NAVTEX : (X) • Weather.
10:07	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas: 222, 223, 224, 225, 226, 227, 228, 229 and 230. • Ice conditions and forecast for Labrador Coast.
	Hopedale	2598J3E
11:07	Cartwright	2598J3E	Radiotelephony • Notices to Shipping: Nearshore – Belle Isle to Cape Chidley. Offshore – North Atlantic, Cape Bauld to Cape Chidley. • Notices to Fish Harvesters (when available).
	Hopedale	2598J3E
11:50	Labrador	518F1B	NAVTEX : (X) • Notices to Shipping.
14:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis and forecasts for marine areas: 222, 223, 224, 225, 226, 227, 228, 229 and 230. • Ice conditions and forecast for Labrador Coast.
	Hopedale	2598J3E
15:50	Labrador	518F1B	NAVTEX : (X) • Weather.
19:50	Labrador	518F1B	NAVTEX : (X) • Weather.
20:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis and forecasts for marine areas: 222, 223, 224, 225, 226, 227, 228, 229 and 230. • Ice Edge & Conditions for Labrador Coast. • Notices to Fish Harvesters (when available).
	Hopedale	2598J3E
23:07	Cartwright	2598J3E	Radiotelephony • Notices to Shipping : Nearshore – Belle Isle to Cape Chidley. Offshore – North Atlantic, Cape Bauld to Cape Chidley.
	Hopedale	2598J3E
23:50	Labrador	518F1B	NAVTEX : (X) • Notices to Shipping (summer)Ice (winter).
Continuous	(Cartwright) Nain	Ch83B	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 222, 223, 224, 225, 226, 227 and 228. • Actual weather observations (when available) for the following sites: Goose Bay – Cartwright – Makkovik – Hopedale – Nain – Mary’s Harbour. • Ice Edge & Conditions for Labrador Coast. • Notices to Shipping: Belle Isle to Cape Chidley. • Notices to Fish Harvesters (when available).
	Goose Bay / Hopedale	Ch21B

TO READ

Time UTC	Site	Frequency or Channel	Contents
01:07	St. Anthony	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 220, 221, 222, 223, 224,225, 226, 227, 228, 229, 230, 235, 237 and 238. • Ice conditions and forecast for the East Coast of Newfoundland, and the Labrador Coast, south of 54N. • Iceberg Bulletin – Newfoundland Coast and Strait of Belle Isle.
01:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas: 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Ice Edge & Conditions for Labrador Coast.
	Hopedale	2598J3E
03:50	Labrador	518F1B	NAVTEX : (X) • Weather.
07:50	Labrador	518F1B	NAVTEX : (X) • Weather.
09:07	St. Anthony	2598J3E	Radiotelephony • Technical marine synopsis and forecasts for marine areas 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Ice conditions and forecast for the East Coast of Newfoundland and the Labrador Coast, south of 54N. • Iceberg Bulletin – Newfoundland East Coast and Strait of Belle Isle
10:07	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas: 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Ice conditions and forecast for Labrador Coast.
	Hopedale
11:07	Cartwright	2598J3E	Radiotelephony • Notices to Shipping: Nearshore – Belle Isle to Cape Chidley. Offshore – North Atlantic, Cape Bauld to Cape Chidley. • Notices to Fish Harvesters (when available).
	Hopedale
11:50	Labrador	518F1B	NAVTEX : (X) • Notices to Shipping.
12:37	St. Anthony	2598J3E	Radiotelephony • Notices to Shipping for an area bounded by Flower’s Cove to the west, Cartwright to the north and Cape Freels to the southeast. • Notices to Fish Harvesters (when available).
13:37	St. Anthony	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238.
14:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis and forecasts for marine areas: 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Ice conditions and forecast for Labrador Coast.
	Hopedale	2598J3E
15:50	Labrador	518F1B	NAVTEX : (X) • Weather.
19:07	St. Anthony	2598J3E	Radiotelephony • Notices to Shipping for an area bounded by Flower’s Cove to the west, Cartwright to the north and Cape Freels to the southeast. • Ice conditions and forecast for the East Coast of Newfoundland, and the Labrador Coast, south of 54N. • Iceberg Bulletin – Newfoundland East Coast and Strait of Belle-Isle. • Notices to Fish Harvesters (when available).
19:37	St. Anthony	2598J3E	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 220, 221, 222, 223, 224, 225, 226, 227, 238, 239, 230, 235, 237 and 238.
19:50	Labrador	518F1B	NAVTEX : (X) • Weather.
20:37	Cartwright	2598J3E	Radiotelephony • Technical marine synopsis and forecasts for marine areas: 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237and 238. • Ice Edge & Conditions for Labrador Coast. • Notices to Fish Harvesters (when available).
	Hopedale	2598J3E
23:07	Cartwright	2598J3E	Radiotelephony • Notices to Shipping : Nearshore – Belle Isle to Cape Chidley. Offshore – North Atlantic, Cape Bauld to Cape Chidley.
	Hopedale
23:50	Labrador	518F1B	NAVTEX : (X) • Notices to Shipping (summer) Ice (winter).
Continuous Labrador North	(Cartwright) Nain	Ch83B	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 220, 221, 222, 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Actual weather observations (when available) for the following sites: Goose Bay – Cartwright – Makkovik – Hopedale – Nain – Mary’s Harbour. • Ice Edge & Conditions for Labrador Coast. • Notices to Shipping: Belle Isle to Cape Chidley. • Notices to Fish Harvesters (when available).
	Goose Bay / Hopedale	Ch21B
Continuous Labrador South	Conche Fox Harbour Comfort Cove	Ch21B	Radiotelephony • Technical marine synopsis, forecasts and wave height forecasts for marine areas 220, 221, 222. 223, 224, 225, 226, 227, 228, 229, 230, 235, 237 and 238. • Actual weather observations (when available) for the following sites: St. Anthony Airport – Englee – La Scie – Blanc Sablon – Mary’s Harbour – Twillingate – Pool’s Island – St. Anthony’s Harbour. • Notices to Shipping for an area bounded by Flower’s Cove to the west, Cartwright to the north and Cape Freels to the southeast. • Ice conditions and forecast for the East Coast of Newfoundland, and the Labrador Coast, south of 54N. • Iceberg Bulletin – Newfoundland East Coast and Strait of Belle Isle. • Notices to Fish Harvesters (when available).
	L’anse aux Meadows Twillingate	Ch83B

COMPLETELY REMOVE 2.1.10, St. Anthony, Newfoundland and Labrador (Pages 51 to 53).

Part 4 - Page 52

AMEND

Table 4-18 – Transmitting sites where NAVTEX Service is available:

Controlled by	Site	Position	Range (NM)	ID 518 kHz (english)	ID 490 kHz (fench)
St. John’s MCTS	St. John’s	47º36’N 52º40’W	300	O
Labrador MCTS	Cartwright	53º42’N 57º01’W	300	X
Sydney MCTS	Port Caledonia	46º11’N 59º54’W	300	Q	J
Saint John MCTS	Yarmouth	43º45’N 66º07’W	300	U	V
Les Escoumins MCTS	Moisie	50º15’N 66º10’W	300	C	D
Sarnia MCTS	Pass Lake	48º34’N 88º39’W	300	P
Prescott MCTS	Ferndale	44º56’N 81º14’W	300	H
Iqaluit MCTS	Iqaluit	63º43’N 68º33’W	300	T	S

The above noted NAVTEX services are provided on a time-shared basis for the broadcast of the following subject indicator content:

1. (A)Navigational Warnings
2. (B)Meteorological Warnings
3. (C)Ice Reports
4. (D)Search and Rescue Information/Tsunami
5. (E)Meteorological Forecasts
6. (G)AIS Service Messages
7. (J)GPS Messages

Broadcast time and content is shown in individual MCTS Centre listings. For Wiarton site consult Prescott MCTS listing. For Moisie site consult Les Escoumins MCTS listing.

TO READ

Controlled by	Site	Position	Range (NM)	ID 518 kHz (englich)	ID 490 kHz (french)
Placentia MCTS	Robin Hood Bay	47º36’N 52º40’W	300	O
Labrador MCTS	Cartwright	53º42’N 57º01’W	300	X
Sydney MCTS	Port Caledonia	46º11’N 59º54’W	300	Q	J
Halifax MCTS	Chebogue	43º45’N 66º07’W	300	U	V
Les Escoumins MCTS	Moisie	50º15’N 66º10’W	300	C	D
Sarnia MCTS	Pass Lake	48º34’N 88º39’W	300	P
Prescott MCTS	Ferndale	44º56’N 81º14’W	300	H
Iqaluit MCTS	Iqaluit	63º43’N 68º33’W	300	T	S

The above noted NAVTEX services are provided on a time-shared basis for the broadcast of the following subject indicator content:

1. (A)Navigational Warnings
2. (B)Meteorological Warnings
3. (C)Ice Reports
4. (D)Search and Rescue Information/Tsunami
5. (E)Meteorological Forecasts
6. (G)AIS Service Messages
7. (J)GPS Messages

Broadcast time and content is shown in individual MCTS Centre listings. For Ferndale site consult Prescott MCTS listing. For Moisie site consult Les Escoumins MCTS listing.

Part 4 - Page 54

REMOVE Figure 4-10 – NAVTEX Coverage – 300 NM – Atlantic Region and REPLACE WITH:

Table of Contents

AMEND Table of Content Page iii, to READ:

PART 2	Facilities Information		1
2.1	Marine Communications and Traffic Services Centre		1
	2.1.1	Halifax, Nova Scotia	1
	2.1.2	Iqaluit, Nunavut	7
	2.1.3	Labrador (Goose Bay), Newfoundland and Labrador	17
	2.1.4	Les Escoumins, Québec	21
	2.1.5	Placentia, Newfoundland and Labrador	27
	2.1.6	Port aux Basques, Newfoundland and Labrador	33
	2.1.7	Prescott, Ontario	37
	2.1.8	Québec, Québec	41
	2.1.9	Sarnia, Ontario	45
	2.1.10	Sydney, Nova Scotia	53
2.2	Canal And Lock Operations		57
2.3	Canal, Port And Lock Operations		57
2.4	Radio Beacon Stations Continuously in Operations		65
2.5	Radar Beacon (Racons)		65
	2.5.1	Atlantic Coast, Gulf and St. Lawrence River to Montréal, Eastern Arctic	65
	2.5.2	Lake Winnipeg	70
	2.5.3	Great Lakes (includes St. Lawrence River to Montréal)	70

---

ATL 106 — Gulf of Maine and Bay of Fundy, First Edition, 2001 —

Chapter 2 — Paragraph 50, after “sounded from the light tower.”`
Insert: A light&bsp; (227.5)  and a radar reflector are shown from a mast, on the rocky intertidal shore, situated 0.2 mile north of the above-mentioned light tower.

(A2015-006.7)

Chapter 2 — Paragraph 89
Delete: “ A light  (209) … head of this wharf.”

(A2015-006.8)

Chapter 2 — Adjacent to paragraph 89, delete the light pictograph.

(A2015-006.9)

Chapter 2 — Delete paragraph 98
Replace by: 98 The Digby Public wharf  is L-shaped, concrete decked, and has three floating wharves which extend SW from the 900-foot (275-m) stem. The facility is operated by the Digby Harbour Port Association. The L-end of the main wharf is 328 feet (100 m) long, with depths of 10 feet (3 m) on the outside face, and depths of 13 feet (3.9 m) on the inside face. The Digby wharf, and a 900-foot (275-m) rock breakwater close NE, form two sheltered boat harbours. There are no berths along the breakwater, but there are berths along the outer portion of the east face of the wharf stem. A light  (206.2), having a red and white triangular daymark, is shown from a mast at the outer end of the breakwater. At the head of the protected harbour, on the west side of the Digby wharf, is a marginal wharf  face 230 feet (70 m) long, with a floating wharf extending SE. Close SW of the marginal wharf, the Royal Western Nova Scotia Yacht Club  operates an 80-berth marina.

(A2015-006.10)

Chapter 2 — Adjacent to paragraph 98, add a light pictograph.

(A2015-006.11)

Chapter 4 — Paragraph 21
Delete: “Pilotage is … areas B and D.”
Replace by: Pilotage is compulsory when proceeding to anchorage area A, while anchorage areas B and D are outside the compulsory pilotage area. Anchorage area B has eight designated anchor berths, while anchorage area D has six designated anchor berths.

(A2015-006.12)

CEN 301 — St. Lawrence River, Montréal to Kingston, Second Edition, 2010 —p>

Chapter 3 — Delete paragraph 141
Replace by : 141 In 2014, the controlling depths were 17 feet [5.2 m] in the upper (west) entrance channel to the mouth of the Oswegatchie River, thence 17 feet [5.2 m] in the city-front channel to the junction with the upper entrance channel, with lesser depths to 13 feet [4 m] along the edges, and 15 feet [4.6 m] in the Oswegatchie River channel to the project limit below the third highway bridge. The lower (east) entrance channel has a project depth of 19 feet [5.8 m] to East Entrance Lighted Buoy 4, however, the local port authority has deepened and widened the channel to their dock. General depths of 19 to 21 feet [5.8 to 6.4 m] were available in the turning basin with lesser depths along the south edge.

(C2015-015.01)

CEN 303 — Welland Canal and Lake Erie, First Edition, 1996 —

Chapter 2 — Delete paragraph 94
Replace by : 94 Cayuga Island, close to the north shore of Niagara River Channel, about 5 [4] miles below Tonawanda Island, is separated from the mainland by Little River, which outlets at either end of the island. Cayuga Creek flows into Little River at about midlength of the island. Little River and Cayuga Creek afford a well-protected harbor for small craft.
94.1 A dredged entrance channel leads from deep water in Niagara River through the lower entrance to Little River. In 2014, the controlling depth was 3½ feet [1.1 m]. The upper entrance to Little River, marked by a private 344° range, had a reported controlling depth of 4 feet [1.2 m] in 1980. Depths inside are about 4 to 7 feet [1.2 to 2.1 m].
94.2 A fixed highway bridge with a reported clearance of 10 feet [3 m] crosses Little River just west of the mouth of Cayuga Creek. An overhead cable with a clearance of 55 feet [16.8 m] crosses the river about 0.35 [0.3] mile west of the bridge. A fixed highway bridge crossing Cayuga Creek just above the mouth has a clearance of 9 feet [2.7 m].

(C2015-016.01)

Chapter 3 — After paragraph 126
Insert: 127 Caution. — A wreck, with a known depth of 27 feet (8.3 m), is SE of the range at 42°45'55''N, 80°03'02.8''W.

(C2015-017.01)

Chapter 3 — Adjacent to paragraph 127, add a caution pictograph.

(C2015-017.02)

---

---

Newfoundland
116.9	Belloram Wharf		47 31 34.8 55 24 33.6	Fl	G	4s	2.1	2	Mast.	Year round. Chart:4831 Edn. 09/15
130.34	Sunken Rock light buoy VSC		Seal Cove, South Coast 47 28 57.4 56 01 23.8	Q(6) +Fl	W	15s	.....	.....	Yellow – black, marked “VSC”	Year round. Chart:4827 Edn. 09/15
270.01	Flat Island Rock - light buoy NJ1		51 59 14.9 055 51 58.2	Fl	G	4s	.....	.....	Green spar, marked "NJ1".	Seasonal. Chart:5030 Edn. 09/15
270.25	Main Tickle Shoal - light buoy NW7		52 33 48.8 055 52 54.6	Fl	G	4s	.....	.....	Green spar, marked "NW7".	Seasonal. Chart:5179 Edn. 09/15
270.9	Northern Ship - light buoy NA3		52 32 11.5 055 59 37.2	Fl	G	4s	.....	.....	Green spar, marked "NA3".	Seasonal. Chart:5179 Edn. 09/15
276.77	Burnt Point Shoal - light buoy NMH2		52 18 48.0 055 49 0.5	Fl	R	4s	.....	.....	Red spar, marked "NMH2".	Seasonal. Chart:5031 Edn. 09/15
276.78	Mary’s Harbour (Inner Harbour) - light buoy NMH3		52 18 35.1 055 50 01.8	Fl	G	4s	.....	.....	Green spar, marked "NMH3".	Seasonal. Chart:5031 Edn. 09/15
277.2	Caribou Run South -light buoy NU2		52 14 51.4 055 38 57.9	Fl	R	4s	.....	.....	Red spar, marked “NU2”.	Seasonal. Chart:5031 Edn. 09/15
279.45	St. Michaels Bay - light buoy NM5		52 44 0.8 055 54 54.5	Fl	G	4s	.....	.....	Green spar, marked "NM5".	Year round. Chart:5032 Edn. 09/15
279.65	Charlottetown Inner light buoy NM12		52 46 34.7 056 06 56	Fl	R	4s	.....	.....	Red spar, marked "NM12".	Seasonal. Chart:5032 Edn. 09/15
280	Red Island		SW side of island. 53 00 37.6 055 45 36.7	Fl	W	3s	28.0	6	Square skeleton tower, red and white rectangular daymark. 4.3	Flash 0.5 s; eclispe 2.5 s. Seasonal. Chart:4712 Edn. 09/15
280.012	Squasho South - North Cardinal light buoy NE		53 05 42 055 51 28.9	Q	W	1s	.....	.....	Black and yellow spar, marked "NE".	Seasonal. Chart:5033 Edn. 09/15
Atlantic
136 H4091.2	Lower Jemseg		On Huestis Island. 45 46 52 066 06 21.5	Fl	R	4s	8.7	4	Square skeleton tower, 3 orange and white rectangular daymarks. 6.5	Operates at night only. Seasonal. Chart:4142 Edn. 09/15 (F15-025)
210 H3906	Schafner Point		On N. side of Annapolis River. 44 42 35.5 065 37 08.6	F	W	.....	13.2	10	White square tower, red upper portion. 11.1	Indicates Goat Island Shoals. Operates at night only. Year round. Chart:4396 Edn. 09/15
1134	Richibucto Gully Inner light Q11		46 42 28.4 064 45 35.2	Q	G	1s	.....	.....	Green, marked "Q11".	Buoy may be repositioned due to shifting channel. Seasonal. Chart:4909 Edn. 09/15 (G15-106)
1135	Richibucto Gully Channel - light buoy Q18		46 42 40.1 064 46 12.5	Fl	R	4s	.....	.....	Red, marked "Q18".	Buoy may be repositioned due to shifting channel. Seasonal. Chart:4909 Edn. 09/15 (G15-107)
1136	North Richibucto Beach Breakwater - light buoy Q22		46 42 47.2 064 46 55.7	Q	R	1s	.....	.....	Red, marked "Q22".	Buoy may be repositioned due to shifting channel. Seasonal. Chart:4909 Edn. 09/15 (G15-109)
1136.1	Richibucto North Beach – light buoy Q24		46 42 53.5 064 47 34.0	Fl	R	4s	.....	.....	Red, marked "Q24".	Seasonal. Operates 24hrs. Chart:4909 Edn. 09/15 (G15-114)
1144	North Richibucto Beach - light buoy Q25		S. of S. end of North Richibucto Beach. 46 42 50.6 064 48 00.2	Q	G	1s	.....	.....	Green, marked "Q25".	Buoy may be repositioned due to shifting channel. Seasonal. Chart:4909 Edn. 09/15 (G15-110)
1147	Richibucto Harbour Outer light buoy Q32		46 42 14.2 064 49 02.9	Q	R	1s	.....	.....	Red, marked "Q32".	Buoy may be repositioned due to shifting channel. Seasonal. Chart:4909 Edn. 09/15 (G15-111)
1150.1	Richibucto River - light buoy Q39		46 41 19 064 50 56	Fl	G	4s	.....	.....	Green spar, marked "Q39".	Seasonal. Operates 24hrs. Chart:4909 Edn. 09/15 (G15-100)
1150.11	Richibucto River - light buoy Q42		46 41 05.9 064 51 18.8	Q	R	1s	.....	.....	Green, marked "Q42".	Seasonal. Operates 24hrs. Chart:4909 Edn. 09/15 (G15-103)
1482.1	Havre de la Grande Entrée - light buoy YC4		47 32 11.9 61 34 33.8	Q	R	1s	.....	.....	Red, marked "YC4".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.2	Havre de la Grande Entrée - light buoy YC5		47 32 13.3 61 34 38.1	Fl	G	4s	.....	.....	Green, marked "YC5".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.3	Havre de la Grande Entrée - light buoy YC9		47 32 48.5 61 34 11	Fl	G	4s	.....	.....	Green, marked "YC9".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.4	Havre de la Grande Entrée - light buoy YC10		47 32 47.5 61 34 06.4	Fl	R	4s	.....	.....	Red, marked "YC10".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.5	Havre de la Grande Entrée - light buoy YC11		47 33 13.7 61 34 04.7	Fl	G	4s	.....	.....	Green, marked "YC11".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.55	Havre de la Grande Entrée - light buoy YC12		47 33 12.6 61 34 00.1	Fl	R	4s	.....	.....	Red, marked "YC12".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)
1482.6	Havre de la Grande Entrée - light buoy YC14		47 33 20.1 61 33 54.3	Fl	R	4s	.....	.....	Red, marked "YC14".	(Winter spar). Year round. Chart:4954 Edn. 09/15 (Q15-101)

---
